Straight Automatic Curve Edge Banding and Cutting Machine Professional Pvc Edge Bander Fully Automatic With Pre Milling
This product is currently out of stock and unavailable. SKU: Straight Automatic Curve Edge Banding and -36310024 Categories: Wood Based Panels Machinery, Woodworking Machinery Description Additional information Description Products Disply Product Paramenters Product size435x92x165cmTotal power 17.5KwPower supply voltage380V/three-phase five-wire 50HzConveying motor 380V22Kw (frequency converter)Air source pressure 0.6mpa-0.8mpaLifting motor380V025Kw (inverter)External suction portdiameter 100mmPolishing motor380V370W (2)Touch screenXinjie industrial touch screenSelection […]
Quality
Certified
Shipping
Worldwide
Support
24/7 Service
Delivery
Fast Lead Time
Products Disply
Product Paramenters
Product size | 435x92x165cm | ||
Total power | 17.5Kw | ||
Power supply voltage | 380V/three-phase five-wire 50Hz | ||
Conveying motor | 380V22Kw (frequency converter) | ||
Air source pressure | 0.6mpa-0.8mpa | ||
Lifting motor | 380V025Kw (inverter) | ||
External suction port | diameter 100mm | ||
Polishing motor | 380V370W (2) | ||
Touch screen | Xinjie industrial touch screen | ||
Selection motor | A 380V 4kw | ||
Inverter | Xinjie Industrial Inverter | ||
Milling motor B | 380V35Kw | ||
Glue pot use temperature | 150-170??/DIV> | ||
Edge strip width | 28mm | ||
The thickness of the edge banding | 1.2mm (related to the material of the edge banding) | ||
Air storage tank volume | 5L | ||
Trimming motor | 380V0.75Kwx2 | ||
Qi head motor | 380V0.37Kwx2 | ||
Sheet width | >100mm | ||
Sheet length | >250mm | ||
Type of edge banding | PVC | ||
Glue pot heating | 1.2KW | ||
Heat gun | 2KW | ||
Edge motor | 380V0.18KW (inverter) | ||
Polishing motor | 380V0.37KWX2 | ||
Slotted motor | 220V0.8KW | ||
Edge banding sheet thickness | 18/22/25MM | ||
Edge speed | 0-12M/MIN (variable speed) (inclined straight edge) | ||
Edge strip width | 20-50MM | ||
Glue pot capacity | 2000ML | ||
Company Profile
ABOUT US
Zhengzhou The Right Time Import And Export Co.. Ltd. designated procurement channels for China Construction Overseas Projects. and is mainly involved in woodworking machinery. construction machinery. machinery accessories. engineering materials and other products. We invest and hold a portable woodworking company in Shandong province and a C N C machinery company in Lunjiao. Foshan City.Combining advanced woodworking production technology and experience at home and abroad. in order to better serve woodworking machinery and support the woodworking industry. we have successively developed. designed and manufactured various type of portable and sliding table saws. the whole house customization straight and curved edge bander. trimming machine. C N C nesting machine. C N C wood router. C N C six-sided drilling and milling processing center. C N C side holes drilling machine. industrial automatic edge banding machine. hinge hole drilling machine. panel saws and other woodworking best-selling products. The products are exported to Europe. America. Southeast Asia. Kazakhstan. Vietnam. India. Brazil. Peru. and other regions and countries.In line with the company philosophy of customer first and pursuit of excellence. the company has brought together a team of technical experts specializing in machine tool design and manufacturing and an import and export service team with more than ten years of rich experience. with good professional quality. We can provide customers with good pre-sale and after-sale technical advice and import and export one-stop service.
Package And Shipping
FAQ
Q1: How to make an order?
Q3: What is your delivery time?
A1:You can order online . Or Email us your details. and we will contact you immediately and help you proceed with the orders.
Q2: Can you offer special discounts to the wholesaler or we make big quantity?
A2:Yes. we will give you best support according to your quantity.
Q3: What is your delivery time?
A3:Normally. we can finish one order at about 25-30days. but the exact time depends on different styles and different quantities you order.
Q4: Can you arrange the shipment by door to door?
A4:We can offer door to door service both by sea and by air. which can save your time and money. Also. we have cooperated forwarder in some countries and can arrange the customs clearance for you.
Q5: Do I have to assemble all items by myself or by my customer himself?
A5:Our packing will be two different ways according to different products. Some are used the KD packing (for some little spare parts). and others need to be assembled. But it is so easy to assemble with the user manual or video teaching.
Q6: What's your warranty?
A6:We normally will provide one years warranties. If the product is caused by factory mistakes. We will give you replacement for the spare parts. If it was damaged during the shipping or other reasons. we will provide the best solutions for you.
Q7:What payment do you accept?
A7:Normally we can provide TT. LC. PAYPAL. ESCROW. WESTERN UNION ect. Any other ideas. please contact us for better support.
A7:Normally we can provide TT. LC. PAYPAL. ESCROW. WESTERN UNION ect. Any other ideas. please contact us for better support.
